Magnesium

Under the hood

One function, five stages.

Follow three lines of Magnesium from source text to a running register machine.

fn total(price, qty, tax)
    return price * qty + tax
end

A table-free scanner turns text into tokens, matching keywords with a hand-coded trie.

fn
total
(
price
,
qty
,
tax
)
return
price
*
qty
+
tax
end

keywordnameoperatorpunctuation

A recursive-descent parser with Pratt-style precedence climbing builds the tree, so * binds tighter than +.

The compiler allocates registers and emits register bytecode. The parameters land in R1, R2 and R3.

0000MULA=4 B=1 C=2R4 = price * qty
0001ADDA=5 B=4 C=3R5 = R4 + tax
0002RETURNA=5 B=1return R5
0003LOADNILA=6implicit
0004RETURNA=6 B=1return null

The actual output of Magnesium’s disassembler for this function. The last two instructions are the return null every function ends with.

magnesium build saves the bytecode as a .mgc file. Loading one runs the verifier over every instruction before any of it executes:

Every opcode is one of the 109
Every register is inside the function’s frame
Every constant index exists, and holds a name where one is expected
Every jump lands on an instruction of the same function
Register counts and arity stay within limits

verified ready to run

Running source directly skips the file: the compiler hands its bytecode straight to the VM.

A computed-goto loop dispatches each instruction. Calling total(4, 3, 1):

MULR4 = R1 * R2
ADDR5 = R4 + R3
RETURNR5

R1: 4
R2: 3
R3: 1
R4: 12
R5: 13

→ 13

Call it from top-level code and total is never called at all: the compiler inlines it, so the caller runs the MUL and ADD itself, with no call and no new frame.

Benchmarks

16 races. 16 wins.

The same 16 programs in Magnesium, Lua 5.4 and CPython. Magnesium is the fastest on every one, from source and from bytecode.

vs Lua 5.4: 1.6×
vs CPython 3: 3.7×

fib35recursive Fibonacci
binary_treesdepth-18 GC pressure
sieve1M-element array
mandelbrot400 × 400
dict_bench250k insert and lookup
arith_looparithmetic loop
call_loop10M function calls
closure_loop5M upvalue mutations
array_looparray loop
object_fields1M struct-field dispatches
gc_alloc50k × 50 arrays
string_concatstring building
control_flowbranches and loops
fallible_lookup3M ? operator lookups
native_len5M native calls
coroutine_switch200k resume and yield

Every run: averages, medians and all five timings, from source and from bytecode

From source, in seconds
Benchmark	Runtime	Average	Median	vs Mg	Runs
fib35	Magnesium	0.390	0.396	1.00×	0.376 0.384 0.396 0.399 0.396
	Lua 5.4	0.625	0.617	1.56×	0.617 0.638 0.656 0.614 0.600
	CPython 3	0.998	1.001	2.53×	1.003 1.005 1.001 0.991 0.990
binary_trees	Magnesium	0.081	0.079	1.00×	0.089 0.079 0.079 0.081 0.079
	Lua 5.4	0.199	0.193	2.43×	0.187 0.193 0.234 0.193 0.189
	CPython 3	0.527	0.514	6.49×	0.585 0.563 0.487 0.486 0.514
sieve	Magnesium	0.092	0.094	1.00×	0.084 0.091 0.095 0.094 0.096
	Lua 5.4	0.112	0.111	1.19×	0.119 0.111 0.104 0.122 0.106
	CPython 3	0.196	0.192	2.05×	0.202 0.192 0.187 0.213 0.188
mandelbrot	Magnesium	0.081	0.082	1.00×	0.082 0.083 0.082 0.079 0.080
	Lua 5.4	0.089	0.088	1.08×	0.087 0.090 0.088 0.088 0.091
	CPython 3	0.380	0.341	4.18×	0.363 0.326 0.341 0.333 0.537
dict_bench	Magnesium	0.121	0.120	1.00×	0.108 0.120 0.130 0.118 0.130
	Lua 5.4	0.207	0.205	1.71×	0.190 0.228 0.216 0.205 0.193
	CPython 3	0.184	0.181	1.51×	0.181 0.175 0.203 0.190 0.170
arith_loop	Magnesium	0.089	0.089	1.00×	0.087 0.088 0.092 0.089 0.089
	Lua 5.4	0.107	0.107	1.20×	0.106 0.109 0.107 0.107 0.104
	CPython 3	0.679	0.670	7.56×	0.711 0.666 0.670 0.684 0.665
call_loop	Magnesium	0.149	0.150	1.00×	0.147 0.152 0.150 0.146 0.151
	Lua 5.4	0.237	0.233	1.55×	0.251 0.234 0.232 0.233 0.233
	CPython 3	1.147	1.139	7.57×	1.194 1.131 1.139 1.139 1.130
closure_loop	Magnesium	0.108	0.107	1.00×	0.111 0.106 0.110 0.105 0.107
	Lua 5.4	0.128	0.128	1.20×	0.128 0.129 0.128 0.125 0.129
	CPython 3	0.464	0.459	4.28×	0.484 0.468 0.459 0.456 0.452
array_loop	Magnesium	0.075	0.075	1.00×	0.075 0.076 0.075 0.076 0.074
	Lua 5.4	0.108	0.107	1.42×	0.106 0.108 0.107 0.110 0.107
	CPython 3	0.456	0.453	6.00×	0.480 0.453 0.463 0.440 0.444
object_fields	Magnesium	0.062	0.063	1.00×	0.059 0.064 0.063 0.064 0.059
	Lua 5.4	0.073	0.072	1.14×	0.072 0.071 0.072 0.074 0.075
	CPython 3	0.154	0.151	2.39×	0.151 0.151 0.151 0.154 0.161
gc_alloc	Magnesium	0.065	0.066	1.00×	0.066 0.067 0.061 0.066 0.066
	Lua 5.4	0.092	0.092	1.39×	0.092 0.091 0.095 0.092 0.090
	CPython 3	0.211	0.211	3.19×	0.207 0.205 0.216 0.215 0.211
string_concat	Magnesium	0.037	0.037	1.00×	0.039 0.036 0.041 0.034 0.037
	Lua 5.4	0.101	0.099	2.68×	0.097 0.107 0.105 0.099 0.098
	CPython 3	0.077	0.076	2.08×	0.081 0.074 0.076 0.075 0.078
control_flow	Magnesium	0.058	0.058	1.00×	0.060 0.058 0.063 0.055 0.055
	Lua 5.4	0.072	0.071	1.22×	0.071 0.066 0.068 0.073 0.080
	CPython 3	0.321	0.321	5.55×	0.321 0.323 0.322 0.319 0.320
fallible_lookup	Magnesium	0.051	0.051	1.00×	0.052 0.049 0.053 0.051 0.051
	Lua 5.4	0.062	0.061	1.19×	0.060 0.062 0.061 0.059 0.067
	CPython 3	0.243	0.244	4.75×	0.248 0.244 0.236 0.243 0.244
native_len	Magnesium	0.073	0.074	1.00×	0.074 0.072 0.071 0.075 0.074
	Lua 5.4	0.139	0.136	1.84×	0.137 0.136 0.151 0.136 0.134
	CPython 3	0.432	0.429	5.79×	0.445 0.428 0.433 0.429 0.425
coroutine_switch	Magnesium	0.052	0.052	1.00×	0.052 0.052 0.052 0.052 0.053
	Lua 5.4	0.253	0.254	4.88×	0.255 0.256 0.253 0.249 0.254
	CPython 3	0.089	0.089	1.70×	0.089 0.092 0.089 0.087 0.089

From bytecode, in seconds
Benchmark	Runtime	Average	Median	vs Mg	Runs
fib35	Magnesium	0.371	0.372	1.00×	0.373 0.367 0.370 0.372 0.372
	Lua 5.4	0.626	0.615	1.65×	0.662 0.613 0.615 0.597 0.641
	CPython 3	1.052	1.058	2.85×	1.020 1.044 1.058 1.061 1.079
binary_trees	Magnesium	0.073	0.072	1.00×	0.075 0.072 0.071 0.074 0.070
	Lua 5.4	0.187	0.182	2.51×	0.172 0.179 0.182 0.214 0.187
	CPython 3	0.540	0.544	7.52×	0.557 0.570 0.534 0.496 0.544
sieve	Magnesium	0.087	0.087	1.00×	0.087 0.089 0.085 0.087 0.086
	Lua 5.4	0.092	0.092	1.05×	0.088 0.096 0.090 0.092 0.094
	CPython 3	0.210	0.207	2.37×	0.192 0.215 0.204 0.207 0.231
mandelbrot	Magnesium	0.082	0.080	1.00×	0.080 0.079 0.080 0.083 0.086
	Lua 5.4	0.093	0.092	1.14×	0.096 0.089 0.092 0.090 0.096
	CPython 3	0.369	0.371	4.63×	0.348 0.371 0.345 0.394 0.385
dict_bench	Magnesium	0.119	0.117	1.00×	0.109 0.123 0.117 0.116 0.129
	Lua 5.4	0.212	0.200	1.71×	0.200 0.219 0.191 0.196 0.251
	CPython 3	0.180	0.180	1.54×	0.180 0.179 0.183 0.176 0.182
arith_loop	Magnesium	0.086	0.086	1.00×	0.087 0.086 0.085 0.086 0.086
	Lua 5.4	0.107	0.106	1.24×	0.110 0.105 0.106 0.106 0.106
	CPython 3	0.681	0.683	7.96×	0.682 0.685 0.685 0.683 0.668
call_loop	Magnesium	0.152	0.154	1.00×	0.154 0.150 0.154 0.154 0.147
	Lua 5.4	0.234	0.234	1.52×	0.231 0.235 0.235 0.234 0.233
	CPython 3	1.153	1.150	7.48×	1.143 1.155 1.144 1.172 1.150
closure_loop	Magnesium	0.105	0.105	1.00×	0.105 0.105 0.105 0.106 0.106
	Lua 5.4	0.129	0.128	1.21×	0.135 0.128 0.128 0.125 0.127
	CPython 3	0.470	0.471	4.48×	0.470 0.472 0.474 0.462 0.471
array_loop	Magnesium	0.074	0.074	1.00×	0.075 0.072 0.074 0.074 0.077
	Lua 5.4	0.107	0.107	1.44×	0.107 0.108 0.105 0.107 0.108
	CPython 3	0.453	0.451	6.06×	0.465 0.451 0.432 0.471 0.447
object_fields	Magnesium	0.065	0.065	1.00×	0.063 0.067 0.062 0.065 0.066
	Lua 5.4	0.073	0.072	1.11×	0.072 0.071 0.070 0.077 0.072
	CPython 3	0.152	0.152	2.34×	0.149 0.158 0.152 0.152 0.151
gc_alloc	Magnesium	0.066	0.067	1.00×	0.067 0.065 0.069 0.061 0.068
	Lua 5.4	0.092	0.091	1.36×	0.090 0.091 0.096 0.090 0.094
	CPython 3	0.213	0.216	3.23×	0.218 0.207 0.216 0.200 0.226
string_concat	Magnesium	0.039	0.039	1.00×	0.039 0.037 0.038 0.040 0.039
	Lua 5.4	0.117	0.113	2.89×	0.111 0.111 0.138 0.114 0.113
	CPython 3	0.077	0.077	1.98×	0.076 0.076 0.079 0.078 0.077
control_flow	Magnesium	0.060	0.061	1.00×	0.060 0.056 0.062 0.062 0.061
	Lua 5.4	0.070	0.071	1.16×	0.070 0.071 0.068 0.071 0.071
	CPython 3	0.327	0.327	5.35×	0.333 0.329 0.325 0.324 0.327
fallible_lookup	Magnesium	0.048	0.047	1.00×	0.047 0.048 0.047 0.047 0.049
	Lua 5.4	0.060	0.059	1.25×	0.059 0.058 0.060 0.061 0.059
	CPython 3	0.256	0.257	5.41×	0.266 0.257 0.247 0.269 0.244
native_len	Magnesium	0.071	0.072	1.00×	0.067 0.072 0.074 0.073 0.070
	Lua 5.4	0.138	0.137	1.91×	0.137 0.145 0.138 0.137 0.134
	CPython 3	0.435	0.434	6.05×	0.434 0.445 0.447 0.420 0.430
coroutine_switch	Magnesium	0.050	0.051	1.00×	0.053 0.051 0.046 0.051 0.050
	Lua 5.4	0.251	0.252	4.98×	0.252 0.254 0.252 0.248 0.251
	CPython 3	0.089	0.087	1.72×	0.087 0.094 0.086 0.091 0.085

The release gate

Every release runs all 16 benchmarks from source and from bytecode, checks that the three languages print the same output, then times five runs after a warmup. If Magnesium’s median is not strictly faster than both Lua 5.4 and CPython on every benchmark, the build fails. No benchmark-only opcodes, no special cases.

Medians of five runs, in seconds, lower is better. Magnesium v1.2.0 built with Clang -O3, Lua 5.4.6 and CPython 3.12.10, on an Intel Core i7-11700KF running Windows 11, October 2026. Averages are geometric means. Run it yourself with make bench.

Bytecode verifier

Damage one byte. Watch it refuse.

Compiled .mgc files are checked before a single instruction runs, so a host can load bytecode it didn’t compile. The test suite damages valid files one field at a time, and the loader must reject every variant.

vm_set_deadlineA time limit for each script
vm_request_cancelStop it from any thread
vm_set_memory_limitA memory cap the collector enforces
vm_set_sandboxNo files, environment, spawning or stray imports

Real bytes from `game.mgc`, built with `magnesium build` from the function above plus `print(total(4, 3, 1))`. Each damage is one of the malformed-bytecode tests, and the message is the loader’s own.

Implementation

Every part, written from scratch.

No parser generator, no JSON library, no runtime dependencies. Just C11.

109opcodes
4inline caches
64bits per value, NaN-boxed
14size classes in the slab allocator

vm.c
VM
Computed-goto dispatch, 109 opcodes, four inline caches, the standard library, native and FFI calls, threads and coroutines.
compiler.c
Compiler
AST to register bytecode: register allocation, peephole fusion, a leaf-function inliner and control-flow lowering.
gc.c
Garbage collector
Generational tri-colour mark-and-sweep with write barriers and a per-VM memory limit.
parser.c
Parser
Recursive descent with Pratt precedence and panic-mode recovery.
typecheck.c
Type checker
Opt-in. Aliases, structural shapes, forward references.
serialize.c
Serializer
The .mgc format and its verifier.
lsp.c
Language server
LSP over stdio, framing written by hand.
object.c
Objects
Strings with ropes, arrays, dicts, functions.
lexer.c
Lexer
Table-free scanner, keyword trie.
mt.c
mt
Installs the runtime, bindings and editor extension.

Embedding

Drop it into your engine.

A small C API, with safe bindings on top. Scripts declare what the host provides, so the checker and the language server know about it too.

RustA safe crate over magnesium-sys; vendored builds by default
C++17Header-only, built with CMake
C#.NET 8 through P/Invoke
CThe low-level boundary under all three

!strict

// Host-provided symbols are declared, not defined.
extern fn read_score(player: string): number
extern const MAX_SCORE: number

// Multi-return errors, with ? propagation.
fn get_score(scores, name)
    return scores<name>?
end

let scores = &< Ada = 10 >
let value, err = get_score(scores, "Grace")
if err then print(err) end

use magnesium::Vm;

let mut vm = Vm::new();
vm.try_set_global_number("MAX_SCORE", 100.0)?;
vm.try_interpret_named(r#"
!strict
extern const MAX_SCORE: number
print(MAX_SCORE)
"#, "game.mg")?;

typedef Value (*NativeFn)(VM *vm, int arg_count, Value *args);

void vm_register_native(
    VM *vm, const char *name, NativeFn function, int arity,
    void *userdata, void (*userdata_finalizer)(void *)
);

fn best(scores)
    let top = 0
    for name, score in scores
        if score > top then top = scroe end
    end
    return top
end

Illustration of the VS Code extension. Undeclared names are compile errors, so they show up as you type.

Tooling

A language server in the binary.

magnesium --lsp starts an LSP server over stdio, with no JSON library. The VS Code extension adds a grammar, auto-indent and the Magnesium Dark theme.

completion
hover
signatureHelp
definition
rename
formatting
documentSymbol
semanticTokens
diagnostics

The language server and extension are still a work in progress and not yet at parity with the core language.

Build it in a minute.

You need git, make and GCC or Clang. On Windows, use LLVM-MinGW.

terminal

git clone https://github.com/EmeraldStudiosG/magnesium-showcase.git
cd magnesium-showcase
make
./magnesium --version

mt, the toolchain manager

mt install          # runtime, library, headers, VS Code extension
mt install rust     # Rust bindings
mt install cpp      # C++17 header-only bindings
mt install csharp   # .NET 8 bindings

View on GitHub Read the Magnesium Book

Flow, the Magnesium mascot: a navy bird in sunglasses, grinning

Meet Flow.

MIT licensed.

VM

Compiler

Garbage collector

Parser

Type checker

Serializer

Language server

Objects

Lexer

mt

Build it in a minute.
